CO2 Incubator

MCO-171AICUVD-PE

Effective capacity
165 Litres
Temperature control range & fluctuation
AT +5 to +50, ±0.1 (AT: 5°C to 35°C)

Features

MCO-171AICUVD-PE: UV Sterilization CO₂ Incubator with LED Technology

The MCO-171AICUVD-PE is a premium variant of the MCO-171AICD-PE, combining its robust features with an added layer of protection through UV-LED germicidal technology. This makes the MCO-171AICUVD-PE particularly well-suited for laboratories that prioritize contamination control while minimizing maintenance requirements.

Key Features and Benefits


UV-LED Germicidal Lamp:

Unlike traditional mercury-based UV lamps, the UV-LED technology used in this model is both mercury-free and highly efficient. Located in the rear duct of the incubator, the UV lamp irradiates the water in the humidifying pan, preventing microbial growth in the water used for maintaining humidity levels. This ensures that the risk of contamination from water sources is greatly reduced without the need for frequent lamp replacements. Additionally, the UV-LED lamp has a longer lifespan than traditional UV lamps, offering extended performance without compromising sterilization efficacy.

Long-Lasting and Efficient UV Performance:

The UV-LED lamp is designed to perform consistently, even with up to 30 door openings per day. This ensures that sterilization effectiveness is maintained over time, making the MCO-171AICUVD-PE highly reliable in busy labs where incubator doors are frequently opened and closed.

Reduced Running Costs:

By using LED technology, the incubator not only improves energy efficiency but also significantly reduces the costs associated with UV lamp replacement. This makes it a cost-effective solution for long-term use, particularly in facilities with heavy usage demands.

Full Color LCD Touchscreen & Data Management:

Similar to the MCO-171AICD-PE, this model includes a high-resolution LCD touchscreen for managing incubator functions. The ability to store and export data via the USB port is especially beneficial for laboratories that need to track environmental conditions over extended periods for research and regulatory purposes.

Seamless Sterilization Process:

With its advanced sterilization and contamination prevention features, the MCO-171AICUVD-PE ensures that cell cultures are consistently grown in optimal conditions. The UV-LED system works alongside the InCu-saFe® germicidal interior to maintain a hygienic environment, reducing the need for frequent manual cleaning and minimizing risks to sensitive samples.

Integrated Shelving for Easy Maintenance:

The interior is designed to simplify cleaning, with integrated shelf supports that minimize surface area and potential contamination sites. This design also increases the number of trays that can be loaded, optimizing the incubator’s capacity and making it ideal for labs that need to grow a large number of cultures simultaneously.

A Complete Sterilization and Culturing Solution

The MCO-171AICUVD-PE combines dry heat sterilization with UV-LED sterilization, creating an all-in-one system that maintains high sterility standards. Its energy-efficient design, extended lamp life, and reduced need for recalibration after sterilization make it perfect for laboratories that require high throughput without compromising on cleanliness or sample safety.



Contact us

Product Photos

Specfications

External Dimensions (W x D x H) (1) 620 x 755 x 905 mm
Internal Dimensions (W x D x H) 490 x 523 x 665 mm
Volume 165 litres
Net Weight 80 kg
Temperature Control Range & Fluctuation AT +5 to +50, ±0.1 (AT: 5°C to 35°C)
Temperature Uniformity (2) ±0.25
CO2 Control Range & Fluctuation (2) 0 to 20, ±0.15
Humidity Level & Fluctuation 95, ±5
Temperature Sensor Thermistor
CO2 Sensor Dual IR
Display Colour LCD touchscreen
Exterior Material Painted steel (Bottom and rear cover have no paint.)
Interior Material Stainless steel copper-enriched alloy
Insulation Material Glass-wool insulation
Heating Method Heater jacket system
Heating Method (3) Dry heat sterilisation, 180°C, 11 hours
Outer Doors 1, Field-reversible
Outer Door Lock Standard
Inner Doors 1
Shelves 4 x Stainless steel copper-enriched alloy
Shelf Dimensions (W x D x H) 470 x 450 x 12 mm
Max. Load Per Shelf 7 kg
Access Port 1
Access Port Position On the back side
Access Port Diameter 30 mm
Power Failure R = (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
Out of Temperature Setting V-B-R = (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
High Temperature V-B-R = (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
CO2 deviation V-B-R = (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
Door Open V-B = (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
Power Supply 220 - 240
Frequency 50/60 Hz
Noise Level (4) 25 dB

Options

UV System Set MCO-LUVSD-PW (Standard in MCO-171AICUVD)
Gas Regulator MCO-010R-PW
Gas Auto Changer

MCO-21GCP-PW

Tray (same as standard accessory) MCO-170ST-PW
Half Tray MCO-25ST-PW
Reinforced Tray (inCu-saFe®) MCO-170RT-PW
Double-stacking Bracket 5) MCO-170PS-PW
Stacking Plate (5) MCO-170SB-PW, MCO-230SB-PW
Roller Base MCO-170RB-PW
Notes:
1) Exterior dimensions of main cabinet only, excluding handle and other external projections.
2) Ambient temperature 23°C, setting 37°C, CO2 5%, no load.
3) Dry heat sterilisation can be performed only for the chamber and inner attachments with standard specifications, not for any other objects.
4) Nominal value.
5) If stacking two incubators, make sure the double-stacking dedicated securing hardware and spacer are used.
6) Only for the Data acquisition system MTR-5000 user. MCO-171AICD series can only be fitted with one communications interface.
7) MCO-171AICD and MCO-171AICUVD are for laboratory use.
