Sliding Door Pharmaceutical Refrigerators

MPR-S1201RXH-PE

Effective capacity
1155 litre
Temperature range
2℃ to 14℃

Features

Twinguard Pharmaceutical Refrigerator with sliding door

Our MPR-S1201RXH-PE Twinguard Pharmaceutical Refrigerator with sliding door, perfectly preserve samples, reagents, and pharmaceuticals through high-reliability temperature control. Use of natural HC refrigerants combined with inverter controlled compressors, reduces power consumption by approx. 77% compared with existing models.

Ultimate Sample Protection

A single unit incorporates two independent refrigerating circuits. Should one circuit experience a problem, the other circuit will continue to maintain in-chamber temperature at SV 5°C ± 3°C. The double-safe circuits ensure preserving the crucial stored items with greater safety.

Improved Sustainability

Natural HC refrigerants, inverter controlled compressors, new Cycle Defrost system, together with enhanced sliding glass doors design, combine to improve temperature management and increase energy efficiency.

User-friendly Design

The ergonomic design provides a clear view of stored items through the large framed windows. The slim profile allows easy retrieval, and the self closing sliding doors makes them ideal for limited spaces.

Environmentally Friendly and Energy Saving

2 Compressors operate in an ON/OFF fashion, “deciding” for the ideal operation. Compressor A and B are controlled on ideal operating patterns, in order to minimize power consumption.

We also offer the MPR-S1201XH-PE, this pharmaceutical refrigerator with sliding door contains 12 shelves instead of 6 shelves and 10 drawers like the MPR-1201RXH-PE.

Contact

Improved temperature management

Due to the new inverter compressors, the speed can be adjusted to gradually maintain the chamber temperature and control it peak to peak: 2.1ºC

Well Insulated Chamber

The high-insulated multi-layered glass with Low-E (Low-Emissivity) coating, encapsulated with argon gas, and hot air blowing from the bottom, significantly reduces condensation on the glass doors, ensuring high temperature performance.

Product Photos

Specfications

External Dimensions (W x D x H) 1800 x 650 x 1824 mm
Internal Dimensions (W x D x H) 1700 x 510 x 1425 mm
Volume 1155 litres
Net Weight 279 kg
Temperature Setting Range +2 to +14 °C
Controller Microcomputer control system
Display OLED
Temperature Sensor Thermistor sensor
Refrigerant HC Refrigerant
Insulation Material Rigid polyurethane foamed-in place
Exterior Material Painted Steel
Interior Material Painted Steel
Outer Doors 2
Outer Door Lock Yes
Shelves 6 (hard steel wire with polyethylene coating)
Drawers 10
Max. Load - Per Shelf/Drawer 50 kg shelf / 20 kg drawer
Max. Load - Total
Access Port 3
Access Port Position Back
Access Port Diameter 30 mm
Casters 6
Interior Light 24 (LED)
Power Failure R
High Temperature V-B-M-R = (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
Low Temperature V-B-M-R = (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
Door Open V-B-M = (R = Remote Alarm, V = Visual Alarm, B = Buzzer Alarm)
Power Supply 230 Hz
Noise Level 42 dB
Compressor Inverter type, Output: 130 W x 2
Evaporator Fin and tube type
Condenser Wire and tube
Remote Alarm Contact Allowable contact capacity: DC 30 V. 2 A
